Billet Turbo Compressor Wheel HOLSET HX82 Cummins 3591712 (102.7/152 mm) 8+8

Product Information

P/N.

405-9901X-854

Item Name

Kinugawa Holset HX82 Turbo Billet Compressor Wheel 102.75/ 152.04 mm Trim 46 / 8+8 Blade

Application

Replace wheel number: 3593927

Fit CHRA:

Fit Turbo # : 3591712

Product Situation

Brand New

Maximum boost 5 bar / 70 Psi

Balance

Balanced By SCHENCK Germany

Ready to competition

Wheel Size

Inducer Dia.: 102.75mm

Exducer Dia. : 152.04mm

Trim: 46

Extend Tapered Tip Exducer dia : 156.76mm

Tip Height: 8.27mm

Super Back Height: 10.08mm

Bore: 11.12 mm

Blade : 8+8

Slimhub Nose: 28mm

Material

Forged Aluminum

Supplier

Kinugawa Turbo

Warranty

One Year

Note

We can customize billet compressor wheel, Please contact us if you need it.
