Kinugawa Billet Turbo Cartridge & Cover BMW 525 325 TDS E34 M51 TD04-15T + 50%HP
MSRP: $599.00
Price: $549.00
You Save: $50.00
Item Number: 333-02302-030
* Whole number only
|
|
| Application |
BMW 77-06400 / 49177-06400 / 2243396 Turbocharger. |
| Wheel spec. |
- Compressor Wheel : 42mm/56mm (Inducer / Exducer Diameter) /(TD04-15T)
- Turbine Wheel : 47.2 / 40 mm (Inducer / Exducer Diameter) ( Standard TD04) |
| Situation |
- Brand New
- Complete cartridge was balanced on Schenck MBRS 110 the best balance machine in the world to make sure it can work well.
- Ready to work.
- 15T Compressor wheel will offer additional 50% airflow than stock 11G compressor wheel to get more torque and HP.
- Bolt up to replace stock CHRA with cover and actuator.
- Journal Bearing System
- Oil-Cooled
|
| Kit. Incl. |
- TD04 cover machined to fit 15T wheel.
- TD04-15T cartridge with Billet Compressor Wheel
- 1.2bar / 18 Psi Actuator
|
| Note |
Turbine Housing is NOT included. |
|
|
|
|
